General Contractors

Our customer-friendly process is designed with you in mind.

Serenity’s sliding door systems save you time and trouble through a headache-free process and easy install. Each system arrives complete with all parts needed and a preloaded track for quick assembly. Through system customization, we can provide a solution for nearly any application. Our system is ADA compliant, lockable, and sound rated. For facilities with existing cased openings, we can even retrofit into your space.

We have resources to support all phases of your project. Get to know our product line, explore our system options, or find helpful documents for construction below.

Downloads

Click here for our Catalog, Cutsheets, CAD/REVIT files, and more.

Design

Click here to view options on mounting, finish, hardware, and more.

System Testing

Click here to view our testing specifications.

Watch our step-by-step video tutorial for a complete walkthrough on how to install your system.

Through quick quotes, complete submittals, and an all-inclusive system, we always make you the priority. Quote requests are typically fulfilled within twenty-four hours.

Healthcare

Commerical Office

Speciality

Hospitality

Helpful Links

Serenity Sliding Door is part of the Riverbend Industries family of brands. Riverbend is a family-owned business focused on improving the comfort, safety, and security of your surroundings by providing high-performance solutions for the HVAC, building envelope, and industrial, and energy markets.

Our Brands

Flush Wood:
Thin layers of wood applied to base for real-wood appearance, structural composite lumber core (SCLC)

Aluminum Stile and Rail with Glass:
Aluminum door leafs with horizontal rails and vertical stiles and glass in between

Hollow Metal:
Reinforced steel sheets filled with insulation materials

Glass Options:

Palladium/Acrovyn:
Flush wood doors combined with rigid vinyl

Door Measurement Width

Clear Open Width	Door Slab Width	Finished Frame Width	Track Width	Rough Opening Width
26	34	31	63	32.5
26.5	34.5	31.5	64	33
27	35	32	65	33.5
27.5	35.5	32.5	66	34
28	36	33	67	34.5
28.5	36.5	33.5	68	35
29	37	34	69	35.5
29.5	37.5	34.5	70	36
30	38	35	71	36.5
30.5	38.5	35.5	72	37
31	39	36	73	37.5
31.5	39.5	36.5	74	38
32	40	37	75	38.5
32.5	40.5	37.5	76	39
33	41	38	77	39.5
33.5	41.5	38.5	78	40
34	42	39	79	40.5
34.5	42.5	39.5	80	41
35	43	40	81	41.5
35.5	43.5	40.5	82	42
36	44	41	83	42.5
36.5	44.5	41.5	84	43
37	45	42	85	43.5
37.5	45.5	42.5	86	44
38	46	43	87	44.5
38.5	46.5	43.5	88	45
39	47	44	89	45.5
39.5	47.5	44.5	90	46
40	48	45	91	46.5
40.5	48.5	45.5	92	47
41	49	46	93	47.5
41.5	49.5	46.5	94	48
*42	*48	*46.5	*95	*48
42	50	47	95	48.5
42.5	50.5	47.5	96	49
43	51	48	97	49.5
43.5	51.5	48.5	98	50
44	52	49	99	50.5
44.5	52.5	49.5	100	51
45	53	50	101	51.5
45.5	53.5	50.5	102	52
46	54	51	103	52.5
46.5	54.5	51.5	104	53
47	55	52	105	53.5
47.5	55.5	52.5	106	54
48	56	53	107	54.5
48.5	56.5	53.5	108	55
49	57	54	109	55.5
49.5	57.5	54.5	110	56
50	58	55	111	56.5
50.5	58.5	55.5	112	57
51	59	56	113	57.5
51.5	59.5	56.5	114	58
52	60	57	115	58.5

Door Measurement Height

Clear Open Height	Door Slab Height	Finished Frame Height	Rough Opening
80	80	80	81
80.5	80.5	80.5	81.5
81	81	81	82
81.5	81.5	81.5	82.5
82	82	82	83
82.5	82.5	82.5	83.5
83	83	83	84
83.5	83.5	83.5	84.5
84	84	84	85
84.5	84.5	84.5	85.5
85	85	85	86
85.5	85.5	85.5	86.5
86	86	86	87
86.5	86.5	86.5	87.5
87	87	87	88
87.5	87.5	87.5	88.5
88	88	88	89
88.5	88.5	88.5	89.5
89	89	89	90
89.5	89.5	89.5	90.5
90	90	90	91
90.5	90.5	90.5	91.5
91	91	91	92
91.5	91.5	91.5	92.5
92	92	92	93
92.5	92.5	92.5	93.5
93	93	93	94
93.5	93.5	93.5	94.5
94	94	94	95
94.5	94.5	94.5	95.5
95	95	95	96
95.5	95.5	95.5	96.5
96	96	96	97
96.5	96.5	96.5	97.5
97	97	97	98
97.5	97.5	97.5	98.5
98	98	98	99
98.5	98.5	98.5	99.5
99	99	99	100
99.5	99.5	99.5	100.5
100	100	100	101
100.5	100.5	100.5	101.5
101	101	101	102
101.5	101.5	101.5	102.5
102	102	102	103
102.5	102.5	102.5	103.5
103	103	103	104
103.5	103.5	103.5	104.5
104	104	104	105
104.5	104.5	104.5	105.5
105	105	105	106
105.5	105.5	105.5	106.5
106	106	106	107
106.5	106.5	106.5	107.5
107	107	107	108
107.5	107.5	107.5	108.5
108	108	108	109
